Microphone cord
Application
・Standard microphone cord.
Features
Excellent flexibility, noise characteristics, and attenuation.
Shape | Part number | Product name | Number of cores | Inner conductor(pcs/mm) | Outline(mm) | Mass(kg/km) | Conductor resistanceΩ/km(20℃) | CapacitancenF/km(1kHz) |
---|---|---|---|---|---|---|---|---|
![]()
Capacitance line-to-line
|
2204-22 | HC-2T1 | 2 | 45/0.12 | 8.0 | 73.9 | 38.2 or less | about 70 |
2204-21 | HC-2T2 | 2 | 30/0.12 | 6.5 | 50.8 | 58.0 or less | about 80 |
