FA cable for fixing
UL STYLE 2464, CSA TYPE AWMMulti pair cables (semi-rigid type)
UL style 2464, CSA type AWM: Multi pair cables (semi-rigid type)
Application
Cable for electronic device wiring
Features
- UL, CSA certified cable
- UL VW-1, CSA FT1 flame retardant
- Uses oil-resistant vinyl material
Specification example
| Size(AWG) | logarithm | Tinned annealed copper wire conductor | Insulator | Sheath | Characteristic | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Composition(pcs/mm) | Outer diameter(mm) | Material | Outer diameter(mm) | Material | Outer diameter(mm) | Rated voltage(V) | Rated temperature(℃) | Insulation resistance15.6℃ (MΩ・ km) |
Conductor resistance20℃ (Ω/km) |
||
| 26 | 1P | 7/0.16 | 0.48 | Semi-rigid lead-free PVC |
0.98 | Lead-free oil resistant PVC |
3.9 | 300 | 80 | 153 or more |
141 ore less |
| 2P | 5.3 | ||||||||||
| 3P | 5.8 | ||||||||||
| 4P | 6.2 | ||||||||||
| 5P | 6.8 | ||||||||||
| 6P | 7.3 | ||||||||||
| 7P | 7.3 | ||||||||||
| 8P | 8.4 | ||||||||||
| 10P | 8.8 | ||||||||||
| 12P | 9.3 | ||||||||||
| 15P | 10.3 | ||||||||||
| 18P | 10.8 | ||||||||||
| 20P | 11.4 | ||||||||||
| 25P | 13.0 | ||||||||||
| 30P | 13.3 | ||||||||||
| 24 | 3P | 7/0.2 | 0.60 | Semi-rigid lead-free PVC |
1.14 | Lead-free oil resistant PVC |
6.2 | 300 | 80 | 153 or more |
90.3 or less |
| 4P | 6.7 | ||||||||||
| 5P | 7.3 | ||||||||||
| 6P | 8.0 | ||||||||||
| 7P | 8.0 | ||||||||||
| 8P | 9.2 | ||||||||||
| 10P | 9.6 | ||||||||||
| 12P | 10.4 | ||||||||||
| 15P | 11.5 | ||||||||||
| 18P | 12.0 | ||||||||||
| 20P | 12.7 | ||||||||||
| 25P | 14.4 | ||||||||||
| 30P | 15.0 | ||||||||||
