UL STYLE 2501Multi core cables
UL style 2501: Multi core cables
Application
Cable for electronic device wiring
Features
- UL approved cable
- UL VW-1 flame retardant
- Uses oil-resistant vinyl material
Specification example
| Size(AWG) | Number of cores | Conductor | Insulator | Sheath | Characteristic | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Composition(pcs/mm) | Outer diameter(mm) | Material | Outer diameter(mm) | Material | Outer diameter(mm) | Rated voltage(V) | Rated temperature(℃) | Insulation resistance15.6℃ (MΩ・ km) |
Conductor resistance20℃ (Ω/km) |
||
| 18 | 2 | 41/0.16 | 1.19 | Lead-free PVC |
2.80 | Lead-free oil resistant PVC |
9.1 | 600 | 105 | 50 or more |
25.0 or less |
| 3 | 9.5 | ||||||||||
| 4 | 10.4 | ||||||||||
| 16 | 2 | 54/0.18 | 1.53 | Lead-free PVC |
3.15 | Lead-free oil resistant PVC |
9.8 | 600 | 105 | 50 or more |
15.0 or less |
| 3 | 10.4 | ||||||||||
| 4 | 11.2 | ||||||||||
| 14 | 2 | 41/0.26 | 1.93 | Lead-free PVC |
3.57 | Lead-free oil resistant PVC |
10.7 | 600 | 105 | 50 or more |
9.39 or less |
| 3 | 11.3 | ||||||||||
| 4 | 12.2 | ||||||||||
| 12 | 2 | 65/0.26 | 2.43 | Lead-free PVC |
4.15 | Lead-free oil resistant PVC |
12.0 | 600 | 105 | 50 or more |
5.92 or less |
| 3 | 12.6 | ||||||||||
| 4 | 13.7 | ||||||||||
| 10 | 2 | 66/0.32 | 3.02 | Lead-free PVC |
4.80 | Lead-free oil resistant PVC |
13.3 | 600 | 105 | 50 or more |
3.85 or less |
| 3 | 14.1 | ||||||||||
| 4 | 15.3 | ||||||||||
