FA cable for moving parts
UL STYLE 20276Multi pair cables
UL style 20276: Multi pair cables
Application
Cable for electronic device wiring
Features
- UL approved robot cable
- UL VW-1 flame retardant
- Uses oil-resistant vinyl material
Specification example
| Size(AWG) | logarithm | Tinned annealed copper wire conductor | Insulator | Sheath | Characteristic | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Composition(pcs/mm) | Outer diameter(mm) | Material | Outer diameter(mm) | Material | Outer diameter(mm) | Rated voltage(V) | Rated temperature(℃) | Insulation resistance15.6℃ (MΩ・ km) |
Conductor resistance20℃ (Ω/km) |
||
| 26 | 1P | 30/0.08 | 0.51 | Lead-free PVC |
0.90 | Lead-free oil resistant PVC |
3.7 | 30 | 80 | 10 or more |
143 or less |
| 3P | 3.9 | ||||||||||
| 2P | 5.2 | ||||||||||
| 3P | 5.7 | ||||||||||
| 4P | 6.1 | ||||||||||
| 5P | 6.6 | ||||||||||
| 6P | 7.1 | ||||||||||
| 7P | 7.6 | ||||||||||
| 8P | 8.3 | ||||||||||
| 10P | 8.9 | ||||||||||
| 12P | 9.2 | ||||||||||
| 15P | 10.4 | ||||||||||
| 20P | 11.5 | ||||||||||
| 25P | 12.8 | ||||||||||
