Interface Cable for Computer
Interface Cable for Computer
Operating temperature 60℃, Operating voltage 125V
Application
For controlling electronic control devices and communication circuits
Features
- Suitable for device connection for RS-422A and RS-485.
- Twisted pair and braided shield with cross-linked polyethylene insulation provide excellent communication characteristics.
- The <PS>E mark is not displayed because it does not conform to the technical standards of the Electrical Appliance and Material Safety Law.
| Item | CO-HC-ESV-3P×7/0.2 | |
|---|---|---|
| Conductor | Material | Tinned annealed copper wire |
| Composition (pcs/mm) | 7/0.2 | |
| Cross-sectional area (m㎡) | 0.22 | |
| Insulator | Material | cross-linked polyethylene |
| Twisting | Number of twisted pairs (pairs) | 3 |
| overall shield | Material | Tinned annealed copper wire |
| jacket | Material | Lead-free PVC |
| Outer diameter (mm) | 6.1 | |
| Rated voltage AC (V) | 125 | |
| Rated temperature (℃) | -10 to +60 | |
| Capacitance | 1kHz、ine-to-line(pF/m) | standard 64 |
| Impedance | 1kHz、ine-to-line(Ω) | standard 100 |
| Standard attenuation | 1MHz、ine-to-line(dB/km) | 30 or less |
